in-lite Big Nero
The BIG NERO LED ground light is the perfect fixture for illuminating tall trees or walls from gravel, grass, pavement or wood.
The BIG NERO can be buried or integrated into various types of concrete products, natural stone and wood. This requires drilling a 142 mm hole.
If the new BIG NERO or BIG NERO NARROW is included in a lighting plan, the following guidelines must be followed: Always use the 10/2 cable, do not exceed the maximum cable length of 40 meters or the number of fixtures (HUB-50 for up to four BIG NERO or BIG NERO NARROW fixtures and up to seven with the HUB-100).
Choose Quantity
With its new single-chip LED and world-leading LEDiL® lens, the BIG NERO has a light distribution of at least 6 1/2 meters, with a light angle of 49 degrees.
The new BIG NERO features the new in-lite Motion technology.
This technology makes it extremely easy to adjust the light source without having to open the fixture. Simply hold the magnet provided up to the in-light logo and the light source will tilt automatically.
Product information Dimensions:
- Height123 mm | 4.84 in
- Diameter170 mm | 6.7 in
- Mounting depth130 mm | 5.12 in
Materials & finish:
- HousingAluminum
- LensGlass
- ColorBlack
- Ring/cover plateAluminum
Technical specifications:
- Voltage12Vs
- Power7,50W
- Electric potential11,90VA
- Light sourceLED
- Burn time25000
- Light typeAccent
- Light angle49°
- Light distribution6.50mtr | 21ft
- Light colorWarm white
- Lighting directionUpwards
- Color temperature3100K
- CRI91
- Net luminous flux488lm
- Luminous efficacy65lm/W
- DimmableNo
- IP classIP-67
- Energy labelA
